Product Description
Bargain Price Only in Alibaba
RF Coaxial Rotary Joint refers to an element which installed on the cable or instrument as transmitting or breaking the line of electrical connections. Also, it belongs to Mechanical & Electrical Integration product.
Contact part adopts rare metal and solid gold plating process, the slip ring of long wear-resisting and antioxidant properties, and ensure the slip ring long service life effectively.
The contact pairing material and its shape makes the signal transmission reliable and continuative even in the application where precision is required in the transmission of the signal
| The Description of Coaxial Connector: |
| Working Temperature | -40℃~ +80℃ |
| Working Humidity | 60% |
| Working Speed | 100rpm max |
| Specific Impedance | 50Ω/75Ω |
| Frequency Range | DC-3GHz |
| Average Load Power | 100W @ DC-2GHz 60W @ DC-3GHz |
| Insulation Resistance | ≥100MΩ@500VDC |
| Dielectric Strength | ≥1000V@50GHz |
| Insertion Loss | <1.5dB@3GHz |
| VSWR | 1.8 max |
| VSWR --WOW | 0.1dB max |
| Phase-WOW | 1° |
| Pull Force | 10N |
| Housing Material | Brass/Zinc Plating |
| Cable Length | 250mm |
| Cable Size | TFLEX-405/RG316 |
| Connector Type | SMA/BNC/TNC/MCX |
| Contact Material | Gold to Gold |
| IP | IP40
|
Option
- High Speed
- Metal Housing
- High Sealing Degree
- Frequency Range
- The Plug of End Lead Wire
Advantage
- Low torque minimizes system torque budget
- Compact design to fit into the most demanding space.
- High bandwidth transfer capability
- Low electrical noise
- Quick shipment per your urgent requirement
- Operating smoothly and reliability
- low resistance
- smooth running
Main Application
- Precise Instrument
- Military Weapon System
- process control equipment
- Indexing tables
- CCTV pan / tilt camera mounts
- Robotics
- Exhibit/display equipment
- Medical equipment
- Aviation, instrument
